GPX Driverless Linear LED Light for reliable energy efficient lighting

DRIVERLESS COEXTRUDED LINEAR

Product Features

Maintenance-Free Driverless Design

Connects directly to AC line voltage without an LED driver or
electrolytic capacitors, for extreme reliability and lifetime. Requires zero maintenance.

Coextruded Copolyester/Aluminum Housing

Our patented process combines copolyester and aluminum together,
with no seals or gaskets. The result is a single piece enclosure with
excellent heatsinking characteristics for long lifetime.

Easy to Install Quick-Connect Cabling

Convenient push-and-click connectors and cabling make GPX Series
fixtures easy to install and daisy chain

Performance Summary

Delivered LED Light Output: Up to 6,000 Lumens
Efficacy: Up to 105 LPW
CRI: Typical 85 CRI
CCT: 5000K & 4000K
Lifetime: Designed to last 75,000 Hours at 25°C
Warranty: 5 Years (See ggled.net for Terms)
Mounting: Ceiling or Wall
Dimensions: Length Varies, Width 1.25” x Height 1.75”
Protection Class: IP67
Dimming: Yes, TRIAC Dimmable
Voltage: 120 VAC Input Only

ACCESSORIES

CONNECTION CABLES

Cable Type Length Wire
GPX-JMP-1 Jumper End-to-End 14 AWG SJOOW
GPX-JMP-2 Jumper 2ft 14 AWG SJOOW
GPX-JMP-4 Jumper 4ft 14 AWG SJOOW
GPX-JMP-8 Jumper 8ft 14 AWG SJOOW
GPX-JMP-10 Leader Cable 10ft 14 AWG SJOOW
GPX-JMP-25 Leader Cable 25ft 14 AWG SJOOW

MOUNTING HARDWARE

Mounting Hardware Description
GPX-MNT-NM Non-Metalic Quick Latch
GPX-MNT-SS Stainless Steel Bolt Latch
