The WPX is a linkable 1″ low-profile luminaire that is designed to withstand prolonged exposure to harsh environments. The seamless housing provides unparalleled chemical resistance and IP68/69K ingress protection.
Harsh Environment LED Luminaire
High Output, Efficient Design in Extremely Compact Housing
Engineered around the latest in LED techology to achieve a low-profile 1″ design. The end result is a strong, compact luminaire with a sleek, clean and modern appearance that is installation friendly and packs a punch at up to 16,000 lumens / 160 LPW. Weighs ~2lbs and can be easily installed by one person.
Extreme Protection Against Environmental Factors
Seamless outer shell provides IP68 / IP69K waterproof protection and is specialized for superior chemical resistance to withstand the most demanding environments. An additional protective coating is available which integrates UV inhibitor and UV blocker for outdoor applications. IK07 rated for impact resistance.
Utilize a Single Power Supply Unit to Energize Multiple Fixtures
Create long linear runs with up to 80’ feet of luminaires on one power supply, not including leader and jumper cables.
Easy to Install Quick-Connect Cabling
Secure, waterproof low-voltage push-and-click cabling allows for a simple, quick and clean installation.
Made in the USA
All of G&G’s products are engineered, tested, manufactured, assembled and shipped from one facility in Clifton Park, New York with industry-leading turnaround times.
Gallery
Product Design
Also Available in Various Color Options
Performance Summary
Delivered Light Output -
Up to 16,000 Lumens
Efficacy -
Up to 160 LPW
CRI -
Typical 85 CRI
CCT -
4000K, 5000K
Lifetime -
Designed to last 100,000 Hours at 25°C
Dimensions -
Length Varies, Width 1.25” x Height 1.75”
Mounting -
Ceiling or Wall
Warranty -
5 Years
Run Length -
Up to 80’ of luminaires (not including jumpers)
Lumen & Power Data
| Length & Output | 5000K | 4000K | Fixture Watts | fixtures supported per power supply | |||||||
| LUMENS | LUMENS PER WATT | LUMENS | LUMENS PER WATT | PSU-80 | PSU-120 | PSU-240 | PSU-320 | PSU-480 | PSU-600 | ||
| WPX8 - SO WPX6 - SO WPX4 - SO WPX2 - SO | 8,000 L 6,000 L 4,000 L 2,000 L | 160 LPW 160 LPW 160 LPW 160 LPW | 7,600 L 5,700 L 3,800 L 1,900 L | 150 LPW 150 LPW 150 LPW 150 LPW | 50 W 37 W 25 W 12 W | 1 2 3 6 | 2 3 4 8 | 4 6 8 14 | 5 7 10 20 | 8 9 13 22 | 10 10 15 22 |
| WPX8 - HO WPX6 - HO WPX4 - HO WPX2 - HO | 12,000 L 9,000 L 6,000 L 3,000 L | 150 LPW 150 LPW 150 LPW 150 LPW | 11,400 L 8,550 L 5,700 L 2,850 L | 140 LPW 140 LPW 140 LPW 140 LPW | 80 W 60 W 40 W 20 W | 0 1 1 3 | 1 1 2 4 | 2 3 5 9 | 3 4 7 13 | 5 7 9 16 | 6 8 9 16 |
| WPX8 - SHO WPX4 - SHO | 16,000 L 8,000 L | 140 LPW 140 LPW | — — | — — | 115 W 58 W | 0 1 | 1 2 | 1 3 | 2 5 | 3 7 | 4 8 |
