The TRX is a harsh environment rated luminaire engineered specifically for transit and automotive maintenance pits. Its 1″ low-profile design enables TRX to be mounted in space restricted locations while heavy duty cabling and push-and-click connectors make it easy to install and daisy chain for long linear runs. The innovative driverless technology connnects directly to AC line voltage, providing extreme reliability and zero maintenance.

Direct AC Driverless Design

Connects directly to AC line voltage without an LED driver or electrolytic capacitors, for ease of use and extreme reliability and lifetime.

Compact Low-Profile Housing

Low-profile, 1” round linear housing provides a remarkably compact design. The patented process combines copolyester and aluminum together with no seals or gaskets. The result is a strong, impact resistant single piece enclosure with excellent durability and heatsinking characteristics for long lifetimes.

Heavy Duty Quick-Connect Cabling

Heavy duty cabling and push-and-click connectors make TRX series fixtures easily to install and daisy chain for long linear runs. Low Smoke Zero Halogen (LSZH) NFPA 130 compliant cabling available.

Made in the USA

All of G&G’s products are engineered, tested, manufactured, assembled and shipped from one facility in Clifton Park, New York with industry-leading turnaround times.

Easy Mount Protective Backplate Option

An optional galvanized steel backplate provides simplified mounting and extra protection in rugged applications. Ideal for maintenance pit lighting.

Product Design

Ready to order?

Performance Summary

Efficacy: 130 LPW
CRI: Typical 85 CRI
CCT: 5000K & 4000K
Lifetime: Designed to last 75,000 Hours at 25°C
Warranty: 5 Years (see ggled.net for terms)
Dimensions: Length Varies, Width 1.25” x Height 1.75”
Protection Class: IP68 Ingress & IK07 Impact
Dimming: Yes, TRIAC Dimmable
Voltage: 120 VAC or 277 VAC Input
Power Factor: 0.9 Nominal
Input Power: Stays Consistent Over Life
Temperature Rating: -40ºC to 55ºC
Total Harmonic Distortion: <20%
Built-In 6KV Surge Protection

Lumen & Power Data

Length & OutputLumensWattageAmps @120VAmps @277V
TRX2
TRX4
2000
5000
16
46
0.13
0.38
0.06
0.17
